Typst¶
組版システム
技術同人誌用にテンプレートを作成してみた
Document¶
公式ドキュメント
https://typst.app/docs
Typst Forum
https://forum.typst.app
Typst Examples Book
https://sitandr.github.io/typst-examples-book/book/about.html
Typst v0.11.1 公式ドキュメントを、日本語コミュニティが非公式に翻訳したもの(翻訳中)
https://typst-jp.github.io/docs/
非プログラミング者のためのTypst公式ドキュメント攻略ガイド
https://zrbabbler.hatenablog.com/entry/2024/05/02/125454
さらばTex。Typstの文法全集 〜1. マークアップ編〜
https://zenn.dev/yuhi_ut/articles/how2write-typst1
Typst 備忘録 -自作書式のサンプル-
https://powercore.hatenablog.com/entry/2023/12/21/114030
Typstの使い方
https://kumaroot.readthedocs.io/ja/latest/typst/typst-usage.html
やりたいことから始めるTypst
https://qiita.com/tomoyatajika/items/649884befe95c5f1dcea
Typst で製本用PDF を作りたい
https://zenn.dev/nabetani/articles/c8deca489b4880
Typstで要素を横並びにして脚注にラベル付けする
https://idukn.com/tech/typst-labels/
Typstでファイルを分割して本を書く
https://zenn.dev/kawaxumax/articles/bf629f56cc2928
typstyle
https://github.com/Enter-tainer/typstyle
自動制御連合講演会テンプレート
https://rengo67.iscie.or.jp/info/manuscript_guidelne/
バーチャル学会要旨テンプレート Typst版
https://github.com/Geson-anko/vconf24_template_typst
About fonts¶
typst フォント まとめ
https://qiita.com/1taroh/items/aee1043d366a4a7c3219
Typstでレポートを作成しよう 前編【Typstシリーズ その2】
https://oucrc.net/articles/yzlr_eor0v/
Typstで英数字・日本語文字と見出し・本文の組み合わせごとにフォントを変える
https://qiita.com/rockwell/items/280b4fd2109ef1e3c802
Setup¶
vscodeに
- Tinymist Typst
を入れるだけ超簡単
Template¶
Requirements¶
- 判型:A5
- フォントサイズ:Meiryo UI,9pt
- 技術同人誌は左トジ
- 余白
- 上余白(天):15mm
- 下余白(地):15mm
- ページ内側の余白(のど、とじしろ):18mm
- ページ外側の余白(小口):10mm
Template本体¶
- 以下のコードブロック を[任意のファイル名].typ として保存
- その際に ¥``` を ``` に置換する(ブログのmarkdownの制限で正確に表現できなくて、全角で書いていますが半角文字の箇所が該当します)
- 同じフォルダに figure.png を格納する(どういう画像でも大丈夫)
- sampleの箇所は書き方を把握したら消す
- 本文に書きたいことを書く→完成!
// 技術同人誌用テンプレート ver 0.1 // kanata //-------------------- // import // https://typst.app/universe //-------------------- // https://typst.app/universe/package/codelst #import "@preview/codelst:2.0.1": sourcecode // https://typst.app/universe/package/gentle-clues/ #import "@preview/gentle-clues:0.8.0": * //-------------------- // ページ設定 // https://typst.app/docs/reference/layout/page/ //-------------------- #set page( paper: "a5", // 用紙サイズ flipped: false, // 用紙の向き(縦) binding: left, // ページの綴じ(技術書は左綴じ) margin: ( // 余白設定 top: 15mm, // 上余白(天) bottom: 15mm, // 下余白(地) inside: 20mm, // ページ内側の余白(のど、とじしろ) outside: 12mm // ページ外側の余白(小口) ), columns: 1, // 段組み numbering: "1", // ページ番号(ノンブル) number-align: center // ページ番号(ノンブル)の位置 ) //-------------------- // フォント設定 // https://typst.app/docs/reference/text/text/ //-------------------- #set text( // 記載の順にフォントを検索します font: ("Meiryo UI","Yu Gothic","Arial"), // フォント設定 /* フォント候補 "Arial","New Computer Modern","Tahoma", "Times New Roman","Verdana", "Meiryo","Meiryo UI", "Yu Gothic","Yu Gothic UI","Yu Mincho", */ size: 9pt, // フォントサイズ lang: "jp" // 言語 ) // コードブロック内のフォント指定 #show raw: set text(font: ("Lucida Console","Meiryo UI","Yu Gothic")) /* コードブロック内のフォント候補(等幅フォント推奨) "BIZ UDGothic","Consolas","Lucida Console", "MS Gothic", */ //-------------------- // 段落設定 // https://typst.app/docs/reference/model/par/ //-------------------- #set par( leading: 0.8em, // 行間 justify: true, // 両端揃え linebreaks: auto, // 改行の判断方法 first-line-indent: 1em // 段落の最初の行のインデント ) // 段落の最初の行がインデントされない問題への対応 // Typst最初の段落の字下げの調整方法 <https://zenn.dev/mkpoli/articles/34a5ea47468979> #show heading: it => { it par(text(size: 0pt, "")) } //-------------------- // 見出し設定 // https://typst.app/docs/reference/layout/block/ //-------------------- // 章、節、項の自動採番 //#set heading( // numbering: " 1.1.1 ", //) // 章の見た目をカスタマイズする //#show heading.where(level: 1): block.with( // width: 100%, // stroke: ( // left: (thickness: 6pt, paint: luma(110), cap: "butt") , // bottom:(thickness: 0.8pt, paint: luma(140), cap: "butt"), // ), // inset: 5pt, //) // 節の見た目をカスタマイズする #show heading.where(level: 2): block.with( width: 100%, stroke: ( left: (thickness: 6pt, paint: luma(140), cap: "butt") , bottom:(thickness: 0.8pt, paint: luma(170), cap: "butt"), ), inset: 5pt, ) // 項の見た目をカスタマイズする #show heading.where(level: 3): block.with( width: 100%, stroke: ( //left: (thickness: 6pt, paint: luma(140), cap: "butt") , bottom:(thickness: 0.8pt, paint: luma(120), cap: "butt",/*dash: "densely-dashed",*/), ), inset: 4pt, ) //-------------------- // PDFメタデータ // https://typst.app/docs/reference/model/document/ //-------------------- #set document( title: "ほげほげほげほげほげほげ(書籍タイトル)", // タイトル author: "Your name", // 著者 date: auto // 日付 ) //-------------------- // タイトル //-------------------- \ \ \ #align(center)[ #text( font: "Meiryo UI", // フォント size: 18pt, // フォントサイズ lang: "jp" // 言語 )[*ほげほげほげほげほげほげ(書籍タイトル)*] \ \ #text( font: "Meiryo UI", // フォント size: 13pt, // フォントサイズ lang: "jp" // 言語 )[*ふがふがふがふが(書籍サブタイトル)*] \ \ #text( font: "Meiryo UI", // フォント size: 13pt, // フォントサイズ lang: "jp" // 言語 )[Your name] ] #pagebreak() //-------------------- // 目次 //-------------------- #show outline.entry.where( level: 1 ): it => { v(14pt, weak: true) strong(it) } #outline( title: "目次", depth: 3, indent: 2em ) //-------------------- // 本文 //-------------------- //-------------------- // 奥付 //-------------------- \ \ \ \ \ \ \ \ \ \ \ \ // 改行で奥付の位置調整 #text( font: "Meiryo UI", // フォント size: 12pt, // フォントサイズ lang: "jp" // 言語 )[ほげほげほげほげほげほげ(書籍タイトル)] #line(length:38em,stroke:1pt) // 罫線 #table( columns: (6em,auto), stroke: none, table.cell(colspan: 2)[2099年99月99日 初版発行], [],[], [発行者],[Your company], [著者], [Your name], [連絡先],[𝕏(旧Twitter): \@Your ID], [印刷会社],[ほげほげ出版], ) #line(length:38em,stroke:1pt) // 罫線 //-------------------- // sample //-------------------- = サンプル = 見出し1 == 見出し2 === 見出し3 ==== 見出し4 - コードブロック \```c #include <stdio.h> int main() { printf("Hello, World!\n"); return 0; } \``` - コードブロック #sourcecode[```c #include <stdio.h> int main() { printf("Hello, World!\n"); return 0; } \```] - 箇条書き + 数字連番の箇条書き - 黒点の箇条書き + 数字連番の箇条書き - 黒点の箇条書き + 数字連番の箇条書き - 黒点の箇条書き - 説明 / 用語: 説明 - 強調 *こんな感じ*になります - 斜体 _こんな感じabc_ abcになります - コメント \``` /* hoge */または// hoge \``` - 表 #figure( table( columns: (1fr, auto, auto), inset: 10pt, align: horizon, table.header( [], [*Area*], [*Parameters*], ), "テストA", $ pi h (D^2 - d^2) / 4 $, [ $h$: height \ $D$: outer radius \ $d$: inner radius ], "テストB", $ sqrt(2) / 12 a^3 $, [$a$: edge length] ), caption: [ 表の名称とかを書く ], kind: "table", supplement: [表] ) - 画像 #figure( image("figure.png", width: 50%), caption: [ 画像の説明とかを書く ], kind: "image", supplement: [図] ) - 脚注 メロスは激怒した。#footnote[なおこの後セリヌンティウスがとばっちりを受けます]必ず、 - gentle-clues #info[ テスト ... ] #tip(title: "テスト1")[テスト2] #clue(title: "テスト3", icon: none, accent-color: orange)[テスト4]
